BL40D
Dual piston BRUSHLESS motor solar pump Replaces most other solar pumps. $660.00
Max flow rate 3.0 gpm at 40 volts and no lift or pressure. Flow decreases as lift and pressure increase.
Max lift 185 feet
Great for low volume wells
or low water needs
No harm to run dry
Can build 85 pounds of pressure
BL40Q
Quad piston BRUSHLESS motor solar pump. Replaces most other solar pumps. $780.00
Max flow at 40 volts with no pressure and no lift 4.5 gpm
Flow decreases as pressure and lift increase
Max lift 185 feet
No harm to run dry
Can build 85 pounds of pressure
Advanced Level Cutoff (ALC1275)
shuts power off to solar pump when storage tank is full. Increases solar pump life!! Order Now
$125.00
No additional parts required comes with 20' of water level sensor wire.
(light gauge wire 16-22 can be used to add more if needed)
Unit mounts to back of solar panels and plugs into panels and pump. Leads go to storage tank and placed at the desired cut off level will shut the power off to the pump when water level reaches the ends of the wire. Power will be resumed to pump when water level falls away. Has an 8 to 10 second delay so waves won't surge the pump.
Solar Boss
Solar Pump System Performance Booster with water level cut off. $225.00
Greatly increases pump performance in low light situations and when pumping from greater depths. It is required on single panel Robison systems when pumping from depths of over 90 feet and on two panel Robison systems when pumping from depths of over 150 feet. It has an ALC level cut off built in helping to add time to pump life.
Click on picture of Solar Boss for full technical data sheet to appear.
Double panel solar pump systems:
K150D with Dual pump $2,050.00** K150Q with Quad pump $2,150.00**
Single panel solar pump systems :
K75D with Dual pump $1,650.00
K75Q with Quad pump$1,770.00
The single panel systems require the use of the Solar Boss Controller for pumping depths greater than 90 ft.
Click on picture above for more info.
Click on pictures for flow charts and printable and readable brochures!
Robison Solar Systems 1604 N Airport Rd Weatherford, OK 73096 Toll Free 866-519-7892
depth to the water or total lift
casing size (diameter of well casing if pumping from one)
geograghic location (Where the well is located)
gallons per day required
contact information to get back to you
NOTE:Lift is from ground level to the top of the water in your well, not from depth pump is set. If you have water at 150 ft. then lift is 150 ft. even if pump is set deeper!
The two panel systems above can pump from depths of 185 ft. to the water, but over 140 ft.of lift the Solar Boss is required to help with start up and low light pumping! This adds $225.00 to the system cost and is strongly recommended!**
Click on picture above for more info.
*Click here to see the flow charts for Robison solar pump systems. (High flow-- deep well pump flow charts links are below.)
When you click on pictures it may be necessary to use the magnifying glass or other enlargement option for proper viewing of the document that appears! They should print in a readable version.
All of our pumps require a minimum of a 4" casing or borehole. We don't know of or offer anything smaller. Our Quad pump requires a 5" casing.
2 yr. warranty on all Robison pumps and controllers! 2 yr. on Grundfos pumps as well.
Click on underlined text above for technical manuals and data on Grundfos pumps.
Click on picture.
Click on picture.
Click on picture.
Grundfos brand high volume or deep well system information below.
Scroll down for more product info!
Grundfos brand pumps.
Grundfos manufactures some of the highest quality and most versatile pumps in the solar water pumping industry. Their quality and performance is amazing. They are more expensive than most other solar pumps but when needed they still prove to be a great value!
Check out these new and exciting products below!
AC-ALC Do away with timers and floats on your AC pumps! Works with 110 or 230 volt.
Emergency Pump Power Converter. Plugs into to 110 AC power and converts to 24 volt DC.
Don't let several days of cloudy weather get you down. You can now run our Robison solar pumps with your generator! Plug this box into your 110 volt generator, or any other 110 volt power supply, and run the pump whenever you need to. The box converts the 110 volt AC power into 24 volt DC power to run your DC motor in your solar pump! What a great option to have with your system!
Only $149.00
This is an incredible electronic water level controller! Have an electrician or well man wire your 110 or 230 volt AC power into this box and then wire your AC submergible pump into it as well. Then simply run the gray wires over to the edge of your tank and bend the red ends down into your tank at where you want to maintain your water level. When water comes against the two leads it will shut your pump off by closing a circuit. When the cattle drink the water and draw the level down below the leads, power will be sent to the pump and it will run until your water level reaches the leads again. No more float switches that freeze up in the winter and no more setting timers keep your tank full with ease.
$179.00
